8712B
8712B vector network analyzer 300kHz-1.3GHz
Description:
The Agilent HP 8712B economy Network Analyzer offers speed, accuracy, and measurement versatility at a price that makes them ideal for high-volume RF component manufacturing. rnThe Agilent 8712B characterizes the transmission / reflection frequency response or measure the insertion loss, delay, power, or SWR of a variety of RF components. rnThe HP 8712B Network Analyzer instrument is compact, integrated, and provides fast, simple, and accurate RF testing. The unit offers high performance RF vector measurement capabilities, including phase, complex impedance, and linear group delay.
Services:
Our full capability facility can repair and calibrate your Keysight Agilent HP 8712B Network Analyzer. We offer Free Estimates and Quick turn around times. Fast!
Specifications:
Frequency Range: 300 kHz to 1300 MHz. Resolution: 1 Hz. Accuracy: < 5 ppm. Output Power Range (standard): <1000 MHz, 0 to 16 dBm; >1000 MHz, 0 to 13 dBm (75 ohm reduces output by 3 dB). Power Range With Attenuator: <1000 MHz, -60 to 13 dBm; >1000 MHz, -60 to 10 dBm (75 ohm reduces output by 3 dB). Test Port Accuracy and Flatness: Standard ±1.0 dB, Opt 1EC ±1.5 dB, Opt 1E1 ±2.0 dB, Opt 1EC and Opt 1E1 ±3.0 dB. Signal Purity Harmonics (at +7 dBm): < 1 MHz < - 20 dBc, > 1 MHz < - 30 dBc. Receiver Frequency Range: Narrowband, 300 kHz to 1300 MHz; Broadband, 10 MHz to 1300 MHz. Dynamic Range Narrowband: <5 MHz, >60 dB; >5 MHz, >100 dB. Dynamic Range Broadband: Internal, >66 dB; External, >66 dB. Maximum Input Narrowband: 10 dBm, 0.8 dBm compression. Maximum Input Broadband: 16 dBm, 0.5 dBm compression. Reflection Port Match: 20 dB. Transmission Port Match: 18 dB typical. System Directivity: 40 dB. Sweep speed (50 ms/sweep)
